| Deublin Teilenummer | Versorgungs anschluss | Rotor anschluss | Gesamtlänge | Gehäuse durchmesser | Maximaler Druck und Medien | Maximale Drehzahl | ||||
|---|---|---|---|---|---|---|---|---|---|---|
|
657-130-124 | G 2"-11 | G 2"-11 RH | 252.5 mm | 9.941" | 118 mm | 4.646" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
657-000-116 | 2"-11.5 NPT | 2"-11.5 NPT RH | 261.5 mm | 10.295" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-130-124 | G 2"-11 | G 2"-11 RH | 252.5 mm | 9.941" | 118 mm | 4.646" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
657-130-125 | G 2"-11 | G 2"-11 LH | 252.5 mm | 9.941" | 118 mm | 4.646" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-050-117 | 2"-11.5 NPT | 2"-11.5 NPT LH | 255.1 mm | 10.043" | 117.4 mm | 4.622" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-045-199 | 2"-11 PT | 2"-11 PT LH | 255.7 mm | 10.067" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-000-124 | 2"-11.5 NPT | G 2"-11 RH | 252.5 mm | 9.941" | 118 mm | 4.646" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-000-117 | 2"-11.5 NPT LH | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM | |||
|
|
657-050-116 | 2"-11.5 NPT | 2"-11.5 NPT RH | 74 mm | 2.913" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-000-117 | 2"-11.5 NPT | 2"-11.5 NPT LH | 261.5 mm | 10.295" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
657-000-125 | G 2"-11 RH | ||||||||
|
|
657-000-125 | 2"-11.5 NPT | G 2"-11 RH | 248 mm | 9.764" | 118 mm | 4.646" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-045-124 | 2"-11 PT | G 2"-11 RH | 246.4 mm | 9.701" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-045-198 | 2"-11 PT | 2"-11 PT RH | 255.1 mm | 10.043" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
|
|
657-045-125 | 2"-11.5 NPT | G 2"-11 LH | 246.4 mm | 9.701" | 117.5 mm | 4.626" |
10 bar Wasser |
150 PSI Wasser |
750 RPM |
