Features.ProductSeries.SwipeForMore
| Features.ProductSeries.DeublinPartNumberDisplay | Features.ProductSeries.SupplyConnectionDisplay | Features.ProductSeries.RotorConnectionDisplay | Features.ProductSeries.OverallLengthDisplay | Features.ProductSeries.HousignDiameterDisplay | Features.ProductSeries.MaxPressureDisplay | Features.ProductSeries.MaxSpeedDisplay | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
BC-54206-48-60 | 3"-8 NPT | 165 mm Flange, 94.386 mm pilot | 6.496" Flange, 3.716" pilot | 200 mm | 7.874" |
6.9 bar Hot Oil 15 bar Steam 20.7 bar Water |
100 PSI Hot Oil 217 PSI Steam 300 PSI Water |
200 RPM | ||
|
BE-43010-20-41 | Welded, 42.55 mm pilot | Welded, 1.675" pilot |
24.1 bar Hot Oil 17.2 bar Steam |
350 PSI Hot Oil 250 PSI Steam |
3 RPM | |||||
|
|
BE-43001-20-41 | 155.96 mm Flange, 73.2 mm pilot | 6.14" Flange, 2.882" pilot | 109.5 mm | 4.311" |
24.1 bar Hot Oil 17.2 bar Steam |
350 PSI Hot Oil 250 PSI Steam |
3 RPM | |||
|
|
BE-32010-16-24 | 1"-11.5 NPT RH |
24.1 bar Hot Oil 17.2 bar Steam |
350 PSI Hot Oil 250 PSI Steam |
3 RPM | ||||||
|
|
355-021-017 | 1-1/2"-12 UNF LH, 39.649 mm pilot | 1-1/2"-12 UNF LH, 1.561" pilot | 82.55 mm | 3.25" |
10 bar Air 69 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 1000 PSI Hydraulic Oil -13.75 PSI Vacuum |
3000 RPM | |||
|
|
350-220-002 | 1"-11.5 NPT RH | 82.55 mm | 3.25" |
10 bar Air 69 bar Hydraulic Oil |
150 PSI Air 1000 PSI Hydraulic Oil |
1500 RPM | ||||
|
350-221-002 | 1"-11.5 NPT RH | 82.4 mm | 3.244" |
10 bar Air 69 bar Hydraulic Oil |
150 PSI Air 1000 PSI Hydraulic Oil |
1500 RPM | ||||
|
1101-195-343 | G 3/8"-19 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 102 mm | 4.016" | |||||
|
|
1101-339-259 | M16x1.5 LH, 16.025 mm pilot | M16x1.5 LH, 0.631" pilot | ||||||||
|
|
1101-654-646 | M12x1.25 LH, 14 mm pilot | M12x1.25 LH, 0.551" pilot | 42.85 mm | 1.687" |
140 bar Water |
2030 PSI Water |
2500 RPM | |||
|
1101-235-343 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 42.85 mm | 1.687" |
103.4 bar Coolant |
1500 PSI Coolant |
15000 RPM | |||
|
250-094-016 | 1"-14 UNS RH, 31.7 mm pilot | 1"-14 UNS RH, 1.248" pilot | 73.03 mm | 2.875" |
10 bar Air 69 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 1000 PSI Hydraulic Oil -13.75 PSI Vacuum |
3500 RPM | |||
|
250-094-020 | 3/4"-14 NPT RH | 73.03 mm | 2.875" |
10 bar Air 69 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 1000 PSI Hydraulic Oil -13.75 PSI Vacuum |
1500 RPM | ||||
|
250-094-002 | 1"-14 UNS RH | 73.03 mm | 2.875" |
10 bar Air 69 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 1000 PSI Hydraulic Oil -13.75 PSI Vacuum |
3500 RPM | ||||
|
250-685-445 | G 3/4"-14 RH | 73.03 mm | 2.875" |
69 bar Hydraulic Oil |
1000 PSI Hydraulic Oil |
3500 RPM | ||||
|
|
250-094-014 | M35x1.5 RH | |||||||||
|
|
250-094-285 | G 3/4"-14 LH | |||||||||
|
|
250-094-284 | G 3/4"-14 RH | 3500 RPM | ||||||||
|
|
250-094-012 | M22x1.5 RH, 27 mm pilot | M22x1.5 RH, 1.063" pilot | ||||||||
|
|
1116-672-043 | 5/8"-18 UNF RH, 15.872 mm pilot | 5/8"-18 UNF RH, 0.625" pilot | 43.64 mm | 1.718" |
69 bar Coolant 10 bar MQL |
1000 PSI Coolant 150 PSI MQL |
12000 RPM |
