| Features.ProductSeries.DeublinPartNumberDisplay | Features.ProductSeries.SupplyConnectionDisplay | Features.ProductSeries.RotorConnectionDisplay | Features.ProductSeries.OverallLengthDisplay | Features.ProductSeries.HousignDiameterDisplay | Features.ProductSeries.MaxPressureDisplay | Features.ProductSeries.MaxSpeedDisplay | ||||
|---|---|---|---|---|---|---|---|---|---|---|
|
2117-001-109 | 1/2"-14 NPT | 3/4"-14 NPT RH | 197 mm | 7.756" | 69.9 mm | 2.752" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
2117-001-105 | 1/2"-14 NPT | G 3/4"-14 RH | 197 mm | 7.756" | 69.9 mm | 2.752" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
2117-001-110 | 1/2"-14 NPT | 3/4"-14 NPT RH | 197 mm | 7.756" | 70 mm | 2.756" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
|
2117-001-103 | 1/2"-14 NPT | 1"-14 UNS RH | 193.8 mm | 7.63" | 70 mm | 2.756" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
|
2117-005-109 | 1/2"-14 NPT | 3/4"-14 NPT RH | 128.2 mm | 5.047" | 69 mm | 2.717" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
|
2117-005-103 | 1/4"-18 NPT | 1"-14 UNS RH | 125 mm | 4.921" | 69.9 mm | 2.752" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
|
2117-005-103 | 1"-14 UNS RH | 69.9 mm | 2.752" |
10 bar Air 207 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 3000 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
